特性/Features
玻璃化温度125℃ E级 (DSC)
TG 125 ℃ E Class (DSC)
粘合强度较高
High adhesive strength
优异的机械性能和电性能
Excellent mechanical properties and electric properties
主要特性/General properties
检测项目 Item | 单位 Unit | 检测条件 Test Condition | 规范值 Spec | 典型值 Typical Value |
密度Density | g/cm3 | ASTMD-792 | 1.30~1.42 | 1.38 |
颜色Color | —— | A | —— | 棕色Brown |
垂直层向弯曲强度 Perpendicular to layer direction Flexural Strength
| MPa | 纵向 LW
| ≥105 | 118 |
冲击强度
| KJ/㎡ | 简支梁 无缺口 纵向 Charpy Method In -notched LW | ≥25 | 40 |
拉伸强度 Tensile Strength | MPa | 纵向 LW
| ≥65 | 69 |
冲击强度
| N | ---- | ≥5400 | 6200 |
垂直层向介电强度 Dielectric Strength (Perpendicular to layer direction) | Mv/m | 90℃±2℃变压器油中 In transformer oil (90℃±2℃) | ≥2.0 | 2.5 |
应用领域/Application
机械、电机、电器设备中作绝缘结构零部件,并可在变压器油中使用
Used for mechanical, electrical, electrical equipment as insulation components, and used in transformer oil
