导热胶膜 HA60PP

特性/ Features

良好的导热性能,普通FR-43-10

Excellent heat dissipation,3-10 times better than normal FR-4

良好的耐化学性能

Superior chemical resistance

优秀的机械加工性

Excellent mechanical processability



主要特性 / General properties

检测项目

Item

单位

Unit

检测条件

Test   Condition

规范值Spec

T2

T3

热导率

Thermal   Conductivity

W/ m·K

ASTM D 5470

≥2.2

≥3.0

玻璃化温度 Tg

DSC

≥150

≥150

击穿电压(100μm

Breakdown Voltage

KV

IPC-TM-650 2.5.6.2

D48/50D0.5/23

≥3

≥3

厚度规格

Thickness   specifications

μm

/

50±15

50±15

75±15

75±15

100±20

100±20

流动度 Resin Flow

%

IPC-TM-650 2.3.17

45±15

40±15

备注:流动度测试,胶膜总厚度在200-230um之间。

Remarks:   Fluidity test, the total thickness of the film is between 200-230um
