特性/Features
玻璃化温度155℃F级 TG155℃ F Class
良好的耐热性 Excellent high heat resistance
机械性能好 Excellent mechnical properties
良好的介电性能和电气性能
Good dielectrical properties and electrical performance
优异的阻燃性,满足UL94-V0
Excellent flame retardant ,meet UL94-V0
主要特性/General properties
检测项目Item | 单位unit | 指标值Spec | 典型值Typical Value | |||
密度Density | g/cm3 | 1.8~2.0 | 1.96 | |||
颜色Color | —— | —— | 绿色Green | |||
垂直层向弯曲强度 Perpendicular to layer Flexural Strength
| 常态 Normal | 纵向 LW | MPa | —— | 574 | |
横向 CW | —— | 602 | ||||
90±2℃ | 纵向 LW | —— | 461 | |||
横向 CW | —— | 450 | ||||
拉伸强度 Tensile Strength | 纵向 LW | Mpa | —— | 513 | ||
横向 CW | —— | 495 | ||||
垂直层向电气强度(90℃±2℃油中,20秒逐级升压) Perpendicular to layer Dielectric Strength(90℃±2℃ oil,with 20 s booster step by step) | MV/m | —— | 19.7 | |||
平行层向冲击强度(简支梁,缺口)Parallel to layer Impact Strength(Charpy Method ,Notched) | 纵向 LW | KJ/m2 | —— | 83 | ||
横向 CW | —— | 54 | ||||
平行层向剪切强度 Parallel Shear Strength | 纵向 LW | MPa | —— | 58.2 | ||
横向 CW | —— | 48.3 | ||||
弯曲弹性模量 (Flexural Mudulus) | 纵向 LW | Mpa | —— | 2.8X104 | ||
横向 CW | —— | 2.57X104 | ||||
平行层向击穿电压(90℃±2℃油中,20秒逐级升压) Parallel to layer breakdown voltage (90℃±2℃ oil,with 20 s booster step by step) | KV | —— | 100 | |||
燃烧性 Flammability | UL V-0 | V0 | ||||
吸水率 Water Absorption | % | ≤0.50 | 0.15 | |||
相比漏电起痕指数 CTI | V | ≥600 | 通过 PASS |
应用领域/Application:
适用于F级电机、电器设备中作绝缘结构零部件
Used in F class motor ,electrical equipment as insulation structure parts .
