特性/Features
玻璃化温度130℃ B级
TG130℃ B Class
高耐热性和平整性
High heat resistance and smoothness
优异的机械性能和电性能
Excellent mechanical properties and electric properties
主要特性/General properties
检测项目 Item | 单位 Unit | 检测条件 Test Condition | 规范值 Spec | 典型值 Typical Value |
密度Density | g/cm3 | ASTMD-792 | 1.90~2.00 | 2.0 |
颜色Colour | —— | A | —— | 水绿色、黄色 Aqua Green,Yellow |
弯曲强度 Flexural Strength | N/mm2 | 纵 向 LW | ≥415 | 480 |
横 向 CW | ≥345 | 450 | ||
体积电阻率 Volume resistivity | MΩNaN | After moisture | ≥106 | 2.0x108 |
吸水率 Water Absorption | % | ISO62 | ≤0.8 | 0.10 |
表面电阻率 Surface resistivity | MΩ | After moisture | ≥104 | 2.0x106 |
耐电弧 Arc Resistance | S | D-48/50+D-0.5/23 | ≥60 | 135 |
击穿电压 Breakdown Voltage | Kv | D-48/50+D-0.5/23 | ≥40 | 60 |
相比漏电起痕指数 CTI | V | IEC60112 | ≥175 | 200 |
应用领域/Applications
电气设备、开关设备、变压器和治具等
Used for electrical equipment, switchgear, transformers and fixture, etc
