特性/Features
玻璃化温度130～155℃ B～F级
TG 130～155℃ B～F Class
优秀的电气性能和耐化学腐蚀性
Excellent electrical properties and resistance to chemical corrosion
良好的机械性能和耐热性
Good mechanical properties and heat resistance
主要特性/General properties
检测项目Item | 单位unit | 检测条件Test Condition | 规范值Spec | 典型值Typical Value |
密度Density | g/cm3 | ASTMD-792 | 1.70～1.90 | 1.85 |
颜色Color | —— | A | —— | 白色、红色White,Red |
弯曲强度 Flexural Strength
| MPa | ISO 178 | ≥100 | 130 |
冲击强度
| KJ/㎡ | 简支梁 缺口 Charpy, Notched | ≥70 | 75 |
吸水率 Water Absorption | % | ISO62 | ≤0.2 | 0.1 |
耐电弧 Arc Resistance | S | ASTM D-495 | ≥60 | 180 |
绝缘电阻 Insulation Resistance | MΩ | IEC167 | ≥107 | 1.2x107 |
电气强度 Dielectric Strength | KV/mm | IEC243 | ≥10 | 12 |
相比漏电起痕指数 CTI | V | IEC112 | ≥600 | 通过 PASS |
燃烧性 Flammability | —— | UL94 | V-0 | 通过 PASS |
应用领域/Application:
电气设备、轨道交通、汽车、变压器和断路器等
Used for electrical equipment, rail transportation, automobiles, transformers and circuit breakers, etc
