HN30

FEATURES

Excellent Electrical Performance under 77GHz

Stable Dielectric property, Non glass fabric effect

Low moisture absorption

Excellent dimensional stability


APPLICATIONS

Automobile Millimeter wave radar

GPS

Power Amplifier


GENERAL PROPERTIES

Item

Test Method

Unit

HN30

Dielectric Constant

IPC TM-650 2.5.5.5

/

3.00+/-0.04

Dissipation Factor

IPC TM-650 2.5.5.5

/

0.0012

TCDK

IPC TM-650 2.5.5.5

ppm /

-50

Peel strength

IPC-TM-650 2.4.8

lb/inch

6

Thermal Conductivity

ASTM-D5470

W/m·K

0.55

Moisture Absorption

IPC TM-650 2.6.2.1A

%

<0.03

CTE (X)

IPC TM-650 2.4.24C

ppm /

18

CTE (Y)

IPC TM-650 2.4.24C

ppm /

17

CTE (Z)

IPC TM-650 2.4.24C

ppm /

26





PRODUCT SPECIFICATIONS

Thickness

Standard Size

Copper Foil

0.005"(0.127mm) ±0.001"

12"*18" (305mmx457mm)

18"*24" (457mmx610mm)

1/2 OZ (17μm)

1 OZ (35μm)

0.010"(0.254mm) ±0.001"

0.020"(0.508mm) ±0.002"

0.030"(0.762mm) ±0.003"
